Ubiquiti U5G-Max-Outdoor UniFi 5G Max with SIM and eSIM Rugged PoE Modem

Rugged Outdoor 5G Performance for Maximum Coverage and Reliability

The Ubiquiti U5G-Max-Outdoor UniFi 5G Max Outdoor PoE Modem delivers full-performance Sub-6 5G connectivity in a hardened IP67 enclosure designed for rooftops, remote sites, mobile setups, and harsh deployment environments. With directional high-gain antennas, dual SIM support, and seamless UniFi WAN integration, it ensures reliable, long-range cellular performance even where indoor reception is weak.

Highlights

• Full-Performance 5G (Up to 3.4 Gbps) with enhanced directional antennas.

• Rugged IP67 Weatherproof Enclosure engineered for outdoor and mobile deployments.

• Dual SIM (nano-SIM + eSIM) with remote SIM support for flexible carrier switching.

• Installs Anywhere using PoE—just plug into any UniFi switch or gateway.

• High-Gain Antenna Array for exceptional long-range signal reception.

• Flexible Mounting including pole and wall mount options.

Key Features

Ultra-Reliable Outdoor 5G Connectivity

• High-Gain Directional Antennas including two DL-optimized 9 dBi elements (85° x 85° beam).

• 3.4 Gbps 5G Performance (NSA) and 1.8 Gbps SA throughput for enterprise-grade uplinks.

• Extensive Global Band Support for Sub-6 5G, LTE, and 3G UMTS.

• Built for Harsh Environments with operating temperatures from -40 to 65°C.

• Remote or Off-Grid Deployments ideal for rooftops, construction sites, and mobile installations.

Dual SIM for Carrier Flexibility

• 1 nano-SIM + 1 nano-SIM or eSIM for multi-carrier redundancy.

• Automatic Failover or Policy-Based Routing via UniFi Network.

• Remote SIM Capability for centralized SIM management when paired with compatible systems.

Seamless UniFi WAN Integration

• Plug-and-Play PoE WAN: Appears instantly as a WAN interface when connected to any PoE port.

• WAN Role Flexibility: Use as primary, load-balanced, or failover uplink.

• Policy-Based Routing for VLAN-specific or client-specific 5G usage.

Hardened Hardware and Mounting Options

• IPX6 / IP67 Weather Resistance with cable-gland door kit.

• Aluminum-Alloy + UV-Stabilized Polycarbonate Housing for long-term durability.

• Pole Mount Support for diameters 1–2.5 inches.

• Wind Resistance: Withstands 91N at 200 km/h (125 mph).

• 2.5 GbE WAN Port for full-speed uplink into your UniFi gateway or switch.

Power and System Features

• PoE Powered with just 14.5W max consumption.

• Embedded 6-Antenna System optimized for outdoor propagation.

• Status LEDs and factory reset button for maintenance.

• Wide Humidity Tolerance (5 to 95 percent noncondensing).

• NDAA Compliant for secure enterprise deployments.

Summary / Conclusion

The Ubiquiti U5G-Max-Outdoor is the ideal solution for delivering enterprise-grade 5G connectivity in harsh outdoor environments. With directional high-gain antennas, rugged IP67 construction, dual SIM support, and seamless UniFi WAN adoption, it brings reliable, high-speed cellular access to rooftops, rural sites, vehicles, and mission-critical field deployments. A powerful choice for organizations that need stable WAN redundancy or primary 5G connectivity anywhere.
