Ubiquiti USW-Pro-XG-10-PoE 400W Pro XG 10-Port L3 10GbE POE+++ Switch
Enterprise-Grade 10-Port 10GbE PoE+++ Layer 3 Switch
The Ubiquiti USW-Pro-XG-10-PoE 400W is a high-performance Layer 3 managed switch, offering 10GbE connectivity, PoE+++ support, and advanced routing features. Designed for businesses, data centers, and professional AV environments, it features (10) 10GbE PoE+++ ports, (2) 10G SFP+ uplinks, and a 400W PoE budget, ensuring uncompromised network speed and reliability.
Highlights
- 10 Multi-Gigabit 10GbE PoE+++ Ports for ultra-fast networking
- (2) 10G SFP+ uplinks for high-speed aggregation and expansion
- 400W total PoE budget to power high-performance devices
- 240 Gbps switching capacity & 120 Gbps non-blocking throughput
- Advanced Layer 3 routing with Inter-VLAN & Static Routing
- Etherlighting™ technology for real-time port status monitoring
- 1U rack-mountable design with DC power backup support
Key Features
High-Speed 10GbE PoE+++ Switching
- 10 PoE+++ (90W) ports support WiFi 7 APs, AV systems, and high-power devices
- Total PoE power budget: 400W for multiple high-demand devices
- Redundant power support with DC backup for network stability
Enterprise-Grade Network Performance
- Switching Capacity: 240 Gbps
- Non-Blocking Throughput: 120 Gbps
- Forwarding Rate: 178.57 Mpps
- Packet Buffer Size: 2MB
Advanced Layer 3 Routing & Traffic Management
- Static Routing & Inter-VLAN Routing for optimized traffic flow
- DHCP Server & Relay for efficient IP management
- MAC-Based ACLs, IP-Based ACLs & Network Isolation for enhanced security
Professional AV & Multicast Optimization
- Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
- Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
- QoS (DSCP), 802.1X, and VLAN support
Enhanced Security & Network Protection
- MAC Address Blocking & Device Isolation
- Port Mirroring & Loop Protection
- Storm Control & Broadcast Rate Limiting
Intelligent Management & Monitoring
- 1.3" LCM Touchscreen Display for real-time network insights
- Cloud-based management via UniFi Controller
- Compact 1U rack-mountable design for space-efficient deployment
Technical Specifications
| Specification | Details |
|---|---|
| Port Layout | (10) 10GbE PoE+++, (2) 10G SFP+ |
| Switching Capacity | 240 Gbps |
| Total Non-Blocking Throughput | 120 Gbps |
| Forwarding Rate | 178.57 Mpps |
| PoE Budget | 400W |
| PoE Power Per Port | PoE (15.4W), PoE+ (30W), PoE++ (60W), PoE+++ (90W) |
| L3 Routing Features | Static Routing, DHCP Server, Inter-VLAN Routing |
| L2 Network Features | LACP, RSTP, VLANs, QoS, IGMP Snooping |
| Power Input | 100-240V AC, 50/60 Hz |
| Redundancy | DC Power Backup (USP-RPS) |
| Mounting | Rack-Mount (1U) |
| Display | 1.3" touchscreen |
| Weight | 4.6 kg (without brackets), 4.7 kg (with brackets) |
| Operating Temperature | -5 to 40°C (23 to 104°F) |
| Certifications | CE, FCC, IC |
Summary
The Ubiquiti USW-Pro-XG-10-PoE is a powerful 10-port Layer 3 managed switch, offering multi-gigabit PoE+++ support, advanced security, and professional AV integration. With 10GbE connectivity, 10G SFP+ uplinks, and a 400W PoE budget, it is the ideal solution for enterprise networking, AV systems, and high-performance infrastructure.
Original: $653.05
-70%$653.05
$195.91
Description
Enterprise-Grade 10-Port 10GbE PoE+++ Layer 3 Switch
The Ubiquiti USW-Pro-XG-10-PoE 400W is a high-performance Layer 3 managed switch, offering 10GbE connectivity, PoE+++ support, and advanced routing features. Designed for businesses, data centers, and professional AV environments, it features (10) 10GbE PoE+++ ports, (2) 10G SFP+ uplinks, and a 400W PoE budget, ensuring uncompromised network speed and reliability.
Highlights
- 10 Multi-Gigabit 10GbE PoE+++ Ports for ultra-fast networking
- (2) 10G SFP+ uplinks for high-speed aggregation and expansion
- 400W total PoE budget to power high-performance devices
- 240 Gbps switching capacity & 120 Gbps non-blocking throughput
- Advanced Layer 3 routing with Inter-VLAN & Static Routing
- Etherlighting™ technology for real-time port status monitoring
- 1U rack-mountable design with DC power backup support
Key Features
High-Speed 10GbE PoE+++ Switching
- 10 PoE+++ (90W) ports support WiFi 7 APs, AV systems, and high-power devices
- Total PoE power budget: 400W for multiple high-demand devices
- Redundant power support with DC backup for network stability
Enterprise-Grade Network Performance
- Switching Capacity: 240 Gbps
- Non-Blocking Throughput: 120 Gbps
- Forwarding Rate: 178.57 Mpps
- Packet Buffer Size: 2MB
Advanced Layer 3 Routing & Traffic Management
- Static Routing & Inter-VLAN Routing for optimized traffic flow
- DHCP Server & Relay for efficient IP management
- MAC-Based ACLs, IP-Based ACLs & Network Isolation for enhanced security
Professional AV & Multicast Optimization
- Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron)
- Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
- QoS (DSCP), 802.1X, and VLAN support
Enhanced Security & Network Protection
- MAC Address Blocking & Device Isolation
- Port Mirroring & Loop Protection
- Storm Control & Broadcast Rate Limiting
Intelligent Management & Monitoring
- 1.3" LCM Touchscreen Display for real-time network insights
- Cloud-based management via UniFi Controller
- Compact 1U rack-mountable design for space-efficient deployment
Technical Specifications
| Specification | Details |
|---|---|
| Port Layout | (10) 10GbE PoE+++, (2) 10G SFP+ |
| Switching Capacity | 240 Gbps |
| Total Non-Blocking Throughput | 120 Gbps |
| Forwarding Rate | 178.57 Mpps |
| PoE Budget | 400W |
| PoE Power Per Port | PoE (15.4W), PoE+ (30W), PoE++ (60W), PoE+++ (90W) |
| L3 Routing Features | Static Routing, DHCP Server, Inter-VLAN Routing |
| L2 Network Features | LACP, RSTP, VLANs, QoS, IGMP Snooping |
| Power Input | 100-240V AC, 50/60 Hz |
| Redundancy | DC Power Backup (USP-RPS) |
| Mounting | Rack-Mount (1U) |
| Display | 1.3" touchscreen |
| Weight | 4.6 kg (without brackets), 4.7 kg (with brackets) |
| Operating Temperature | -5 to 40°C (23 to 104°F) |
| Certifications | CE, FCC, IC |
Summary
The Ubiquiti USW-Pro-XG-10-PoE is a powerful 10-port Layer 3 managed switch, offering multi-gigabit PoE+++ support, advanced security, and professional AV integration. With 10GbE connectivity, 10G SFP+ uplinks, and a 400W PoE budget, it is the ideal solution for enterprise networking, AV systems, and high-performance infrastructure.
